Acid-Resistant Lining Enquiries: Specify the System, Not Just the Brick
Chemical-service lining enquiries should describe the liquid, temperature, substrate, membrane, mortar, joints, and inspection plan.
An acid-resistant brick lining is a system of brick, mortar, joints, possible membrane, substrate, and workmanship. Asking only for an "acid-proof brick" can leave the most important compatibility questions unanswered. The liquid that reaches a joint or a damaged membrane can affect the substrate even when the brick itself looks sound.
A useful enquiry begins with the actual exposure and the full lining cross-section.
Describe the chemistry and operation
Identify the chemicals, concentrations, normal and upset temperatures, immersion or splash exposure, cleaning method, and any solids or abrasion. A laboratory resistance statement for one reagent is not a blanket approval for every mixed process stream. If the composition varies, give the range and the conditions under which it changes.
State whether the lining sits in a vessel, floor, drain, channel, or containment area. Those locations have different movement, loading, and access requirements.
Show the substrate and layers
Provide the substrate material and condition, existing membrane or protective layer, thickness available, drainage details, and any design standard or project specification. The jointing material and membrane must suit the exposure and each other. Compatibility cannot be inferred from a brick name alone.
Mark penetrations, corners, and terminations on a drawing. These are common places for leakage paths or construction difficulties. The design should explain how the protective system ends and how it ties into adjacent construction.
Define acceptance and repair access
Agree on brick dimensions, joint method, installation sequence, inspection points, and any required test of the completed system. Record how damaged areas will be repaired later. A system that performs well in a broad open floor may be difficult to maintain around equipment bases or narrow drains.
At receipt, verify the supplied components against the approved schedule. Do not substitute a mortar or membrane without the designer's review because another material happens to be available on site.
Chemical resistance belongs to the assembled lining, not to one material in isolation.
Send evidence that supports selection
Include process data, drawings, substrate history, known leaks or failures, and the required shutdown window. If the old lining failed, photographs showing the joint and membrane condition can help identify whether the problem began in chemistry, movement, or construction.
Questions that expose specification gaps
Ask whether the process can concentrate the chemical at an evaporation line, whether the lining will see cleaning chemicals, and whether temperature changes during washing or start-up. Note any mechanical traffic, dropped tools, or solids that may abrade the floor or channel. These details can affect joints and protective layers as much as brick selection.
Identify who designs and supplies each part of the system. A brick supplier, membrane contractor, and installer may otherwise assume another party has checked compatibility at the interface. Request written confirmation of the jointing and termination details and keep approved product data together. Where testing is specified, state the method and acceptance criteria before construction begins.
During maintenance, inspect recurring leaks by location rather than replacing only visibly damaged bricks. Follow the path toward the substrate and examine nearby joints, corners, and penetrations. A sound-looking brick surface can conceal a failed joint or membrane. The repair scope should address the path that allowed exposure.
Ask the designer how the system will be inspected after service begins. A hidden membrane or substrate cannot be checked in the same way as an exposed brick face. Planned inspection points and a response to an early leak should be agreed before the area is put into operation.
Royal's acid-resistant brick range can start the material discussion. Send the chemical exposure and lining section so the complete system can be reviewed.
