Product range
Our Products
All 90 products we manufacture. Filter by category, chemical analysis, or technical properties — or pick a category below for the full range and its typical applications.
Showing 90 of 90 products
Technical Properties
| PCE | 28 / 1649 |
| App Porosity | 26% |
| BDDensity | 1.9 g/cm³ |
| CCS | 250 Kg/cm² |
| RUL | 1300°C |
| PLC | +/-1% at 1300/3 hrs |
Chemical Analysis
| Al2O3 | 28% |
| Fe2O3 | 3.5% |
Additional Information
| Size Tolerance | ±1.5% or ±2 mm |
Technical Properties
| PCE | 30 / 1665 |
| App Porosity | 24% |
| BDDensity | 2.1 g/cm³ |
| CCS | 350 Kg/cm² |
| RUL | 1400°C |
| PLC | +/-1% at 1350/3 hrs |
Chemical Analysis
| Al2O3 | 40% |
| Fe2O3 | 2.8% |
Additional Information
| Size Tolerance | ±1.5% or ±2 mm |
Technical Properties
| PCE | 32 / 1717 |
| App Porosity | 21% |
| BDDensity | 2.25 g/cm³ |
| CCS | 400 Kg/cm² |
| RUL | 1400°C |
| PLC | +/-0.8% at 1400/3 hrs |
Chemical Analysis
| Al2O3 | 45% |
| Fe2O3 | 3.5% |
Additional Information
| Size Tolerance | ±1.5% or ±2 mm |
Technical Properties
| PCE | 30 / 1665 |
| App Porosity | 18% |
| BDDensity | 2.15 g/cm³ |
| CCS | 400 Kg/cm² |
| RUL | 1350°C |
| PLC | +/-0.8% at 1350/3 hrs |
Chemical Analysis
| Al2O3 | 30% |
| Fe2O3 | 1.8% |
Additional Information
| Size Tolerance | ±1 mm or ±2 mm |
Technical Properties
| PCE | 33 / 1743 |
| App Porosity | 17% |
| BDDensity | 2.25 g/cm³ |
| CCS | 500 Kg/cm² |
| RUL | 1480°C |
| PLC | +/-0.8% at 1450/3 hrs |
Chemical Analysis
| Al2O3 | 42% |
| Fe2O3 | 1.3% |
Additional Information
| Size Tolerance | ±1 mm or ±2 mm |
Technical Properties
| PCE | 34 / 1765 |
| App Porosity | 18% |
| BDDensity | 2.30 g/cm³ |
| CCS | 500 Kg/cm² |
| RUL | 1500°C |
| PLC | +/-0.8% at 1500/2 hrs |
Chemical Analysis
| Al2O3 | 45% |
| Fe2O3 | 1.3% |
Additional Information
| Size Tolerance | ±1 mm or ±2 mm |
Technical Properties
| PCE | 33 / 1743 |
| App Porosity | 22% |
| BDDensity | 2.35 g/cm³ |
| CCS | 400 Kg/cm² |
| RUL | 1410°C |
| PLC | +/-1% at 1400/3 hrs |
Chemical Analysis
| Al2O3 | 50% |
| Fe2O3 | 3.5% |
Additional Information
| Size Tolerance | ±1.5% or ±2 mm |
Technical Properties
| PCE | 34 / 1765 |
| App Porosity | 18% |
| BDDensity | 2.35 g/cm³ |
| CCS | 500 Kg/cm² |
| RUL | 1500°C |
| PLC | +/-0.5% at 1500/3 hrs |
Chemical Analysis
| Al2O3 | 50% |
| Fe2O3 | 1.3% |
Additional Information
| Size Tolerance | ±1.5% or ±2 mm |
Technical Properties
| PCE | 35 / 1785 |
| App Porosity | 21% |
| BDDensity | 2.40 g/cm³ |
| CCS | 450 Kg/cm² |
| RUL | 1480°C |
| PLC | +/-1% at 1500/3 hrs |
Chemical Analysis
| Al2O3 | 55% |
| Fe2O3 | 2.0% |
Additional Information
| Size Tolerance | ±1.5% or ±2 mm |
Technical Properties
| PCE | 35 / 1785 |
| App Porosity | 22% |
| BDDensity | 2.50 g/cm³ |
| CCS | 500 Kg/cm² |
| RUL | 1450°C |
| PLC | +/-1.8% at 1500/2 hrs |
Chemical Analysis
| Al2O3 | 60% |
| Fe2O3 | 3.5% |
Additional Information
| Size Tolerance | ±1.5% or ±2 mm |
Technical Properties
| PCE | 36 / 1804 |
| App Porosity | 22% |
| BDDensity | 2.45 g/cm³ |
| CCS | 450 Kg/cm² |
| RUL | 1480°C |
| PLC | +/-0.8% at 1500/2 hrs |
Chemical Analysis
| Al2O3 | 60% |
| Fe2O3 | 2.2% |
Additional Information
| Size Tolerance | ±1.5% or ±2 mm |
Technical Properties
| PCE | 36 / 1804 |
| App Porosity | 18% |
| BDDensity | 2.45 g/cm³ |
| CCS | 550 Kg/cm² |
| RUL | 1620°C |
| PLC | +/-0.4% at 1600/2 hrs |
Chemical Analysis
| Al2O3 | 60% |
| Fe2O3 | 0.8% |
Additional Information
| Size Tolerance | ±1.5% or ±2 mm |
Technical Properties
| PCE | 36 / 1804 |
| App Porosity | 18% |
| BDDensity | 2.45 g/cm³ |
| CCS | 500 Kg/cm² |
| RUL | 1500°C |
| PLC | +/-0.3% at 1500/2 hrs |
Chemical Analysis
| Al2O3 | 58% |
| Fe2O3 | 1.5% |
Additional Information
| Size Tolerance | ±1.5% or ±2 mm |
Technical Properties
| PCE | 36 / 1804 |
| App Porosity | 16% |
| BDDensity | 2.50 g/cm³ |
| CCS | 550 Kg/cm² |
| RUL | 1510°C |
| PLC | +/-0.2% at 1500/2 hrs |
Chemical Analysis
| Al2O3 | 62% |
| Fe2O3 | 1.3% |
Additional Information
| Size Tolerance | ±1.5% or ±2 mm |
Technical Properties
| PCE | 36 / 1804 |
| App Porosity | 22% |
| BDDensity | 2.60 g/cm³ |
| CCS | 550 Kg/cm² |
| RUL | 1460°C |
| PLC | +/-2% at 1500/2 hrs |
Chemical Analysis
| Al2O3 | 70% |
| Fe2O3 | 3.5% |
Additional Information
| Size Tolerance | ±1.5% or ±2 mm |
Technical Properties
| PCE | 37 / 1820 |
| App Porosity | 22% |
| BDDensity | 2.60 g/cm³ |
| CCS | 600 Kg/cm² |
| RUL | 1460°C |
| PLC | +/-2% at 1500/2 hrs |
Chemical Analysis
| Al2O3 | 70% |
| Fe2O3 | 3% |
Additional Information
| Size Tolerance | ±1.5% or ±2 mm |
Technical Properties
| PCE | 37 / 1820 |
| App Porosity | 22% |
| BDDensity | 2.55 g/cm³ |
| CCS | 600 Kg/cm² |
| RUL | 1480°C |
| PLC | +/-2% at 1500/2 hrs |
Chemical Analysis
| Al2O3 | 70% |
| Fe2O3 | 2.5% |
Additional Information
| Size Tolerance | ±1.5% or ±2 mm |
Technical Properties
| PCE | 37 / 1820 |
| App Porosity | 18% |
| BDDensity | 2.60 g/cm³ |
| CCS | 600 Kg/cm² |
| RUL | 1550°C |
| PLC | +/-0.5% at 1550/2 hrs |
Chemical Analysis
| Al2O3 | 70% |
| Fe2O3 | 1.5% |
Additional Information
| Size Tolerance | ±1.5% or ±2 mm |
Technical Properties
| PCE | 37 / 1820 |
| App Porosity | 18% |
| BDDensity | 2.55 g/cm³ |
| CCS | 600 Kg/cm² |
| RUL | 1650°C |
| PLC | +/-0.3% at 1600/2 hrs |
Chemical Analysis
| Al2O3 | 70% |
| Fe2O3 | 0.4% |
Additional Information
| Size Tolerance | ±1.5% or ±2 mm |
Technical Properties
| PCE | 37 / 1820 |
| App Porosity | 22% |
| BDDensity | 2.65 g/cm³ |
| CCS | 600 Kg/cm² |
| RUL | 1480°C |
| PLC | +/-2% at 1500/2 hrs |
Chemical Analysis
| Al2O3 | 75% |
| Fe2O3 | 3.5% |
Additional Information
| Size Tolerance | ±1.5% or ±2 mm |
Technical Properties
| PCE | 37 / 1820 |
| App Porosity | 20% |
| BDDensity | 2.75 g/cm³ |
| CCS | 700 Kg/cm² |
| RUL | 1500°C |
| PLC | +/-1.2% at 1550/2 hrs |
Chemical Analysis
| Al2O3 | 79% |
| Fe2O3 | 1.9% |
| P2O5 | - |
Additional Information
| Size Tolerance | ±1.5% or ±1.5 mm |
Technical Properties
| PCE | 37 / 1820 |
| App Porosity | 18% |
| BDDensity | 2.75 g/cm³ |
| CCS | 700 Kg/cm² |
| RUL | 1550°C |
| PLC | +/-0.8% at 1550/2 hrs |
Chemical Analysis
| Al2O3 | 79% |
| Fe2O3 | 1.4% |
Additional Information
| Size Tolerance | ±1.5% or ±1.5 mm |
Technical Properties
| PCE | 37 / 1820 |
| App Porosity | 17% |
| BDDensity | 2.75 g/cm³ |
| CCS | 750 Kg/cm² |
| RUL | 1540°C |
| PLC | +/-1% at 1550/2 hrs |
Chemical Analysis
| Al2O3 | 80% |
| Fe2O3 | 1.4% |
| P2O5 | 1.5% |
Additional Information
| Size Tolerance | ±1.5% or ±1.5 mm |
Technical Properties
| PCE | 38 / 1835 |
| App Porosity | 18% |
| BDDensity | 2.80 g/cm³ |
| CCS | 750 Kg/cm² |
| RUL | 1550°C |
| PLC | +/-0.8% at 1550/2 hrs |
Chemical Analysis
| Al2O3 | 84% |
| Fe2O3 | 1.3% |
Additional Information
| Size Tolerance | ±1% or ±1.5 mm |
Technical Properties
| PCE | 38 / 1835 |
| App Porosity | 17% |
| BDDensity | 2.80 g/cm³ |
| CCS | 800 Kg/cm² |
| RUL | 1550°C |
| PLC | +/-0.8% at 1550/2 hrs |
Chemical Analysis
| Al2O3 | 84% |
| Fe2O3 | 1.3% |
| P2O5 | 1.5% |
Additional Information
| Size Tolerance | ±1% or ±1.5 mm |
Technical Properties
| PCE | 38 / 1835 |
| App Porosity | 16% |
| BDDensity | 2.90 g/cm³ |
| CCS | 800 Kg/cm² |
| RUL | 1580°C |
| PLC | +/-0.5% at 1550/2 hrs |
Chemical Analysis
| Al2O3 | 90% |
| Fe2O3 | 1.21% |
Additional Information
| Size Tolerance | ±1 mm or ±2 mm |
Technical Properties
| PCE | 38 / 1835 |
| App Porosity | 18% |
| BDDensity | 2.90 g/cm³ |
| CCS | 800 Kg/cm² |
| RUL | 1630°C |
| PLC | +/-0.3% at 1600/2 hrs |
Chemical Analysis
| Al2O3 | 90% |
| Fe2O3 | 0.3% |
Additional Information
| Size Tolerance | ±1 mm or ±2 mm |
Technical Properties
| PCE | 36 / 1804 |
| App Porosity | 18% |
| BDDensity | 2.55 g/cm³ |
| CCS | 600 Kg/cm² |
| PLC | +/-0.3% at 1450/2 hrs |
Chemical Analysis
| Al2O3 | 70% |
| Fe2O3 | 0.5% |
Additional Information
| Size Tolerance | ±1 mm or ±2 mm |
Technical Properties
| PCE | 37 / 1835 |
| App Porosity | 16% |
| BDDensity | 2.65 g/cm³ |
| CCS | 700 Kg/cm² |
| PLC | +/-0.25% at 1450/2 hrs |
Chemical Analysis
| Al2O3 | 60% |
| Fe2O3 | 0.4% |
| ZrO2 | 13.5% |
Additional Information
| Size Tolerance | ±1 mm or ±2 mm |
Technical Properties
| Water Absorption | 3% |
| Cold Crushing Strength | 70 Kg/cm² |
| Flexural Strength | 10 N/mm² |
| Acid Resistance | 2.5% loss in weight |
Chemical Analysis
| SiO3 | 68% |
| Al2O3 | 24% |
| Fe2O3 | 1.8% |
| TiO2 | 2.1% |
| CaO+MgO | 0.5% |
| Na2O+K2O | 3.4% |
Additional Information
| Application Area | Thermal power plant chimney & acid storage tank & floor |
Technical Properties
| Service Temp | 700°C |
| Grain Size | max 5 mm |
| Bulk Density110 | 1.95-2.10 g/cc |
| CCS110 | 210 Kg/cm² |
| CCS500 | 250 Kg/cm² |
| CCS800 | 310 Kg/cm² |
| PLC110 | +/-0.60% |
| PLC500 | +/-0.25% |
| Thermal Conductivity300 | 0.7 kcal/m·hr·°C |
| Thermal Conductivity500 | 0.7 kcal/m·hr·°C |
| Liquid Powder Ratio | 1:4 |
Chemical Analysis
| Al2O3 | 15-20% |
| SiO2 | 70-75% |
Additional Information
| Method | Ramming |
| Shelf Life | 12 months |
| Application Area | Acid-resistant monolithic lining |
Technical Properties
| PCEOrton | 27 / 1640 |
| Grain Size | 0 - 1 mm |
| Service Temp | 1350°C |
| Sintering Temp | 1100°C |
Chemical Analysis
| Al2O3 Min | 30% |
| Fe2O3 Max | 3.0% |
Additional Information
| Setting | Ceramic |
| Size Tolerance | 95% passing through max grain size |
| Pack Size | 1 Bag = 50 Kg |
Technical Properties
| PCEOrton | 31 / 1683 |
| Grain Size | 0 - 1 mm |
| Service Temp | 1400°C |
| Sintering Temp | 1100°C |
Chemical Analysis
| Al2O3 Min | 40% |
| Fe2O3 Max | 3.5% |
Additional Information
| Setting | Ceramic |
| Size Tolerance | 95% passing through max grain size |
| Pack Size | 1 Bag = 50 Kg |
Technical Properties
| PCEOrton | 31/32 1683/1717 |
| Grain Size | 0 - 1.5 mm |
| Service Temp | 1550°C |
| Sintering Temp | 1100°C |
Chemical Analysis
| Al2O3 Min | 50% |
| Fe2O3 Max | 3.8% |
Additional Information
| Setting | Air Setting |
| Size Tolerance | 95% passing through max grain size |
| Pack Size | 1 Bag = 50 Kg |
Technical Properties
| PCEOrton | 31/32 1683/1717 |
| Grain Size | 0 - 0.5 mm |
| Service Temp | 1550°C |
| Sintering Temp | 1100°C |
Chemical Analysis
| Al2O3 Min | 50% |
| Fe2O3 Max | 3.8% |
Additional Information
| Setting | Air Setting |
| Size Tolerance | 95% passing through max grain size |
| Pack Size | 1 Bag = 50 Kg |
Technical Properties
| PCEOrton | 31 / 1683 |
| Grain Size | 0 - 0.5 mm |
| Service Temp | 1500°C |
| Sintering Temp | 1100°C |
Chemical Analysis
| Al2O3 Min | 40% |
| Fe2O3 Max | 2.0% |
Additional Information
| Setting | Air Setting |
| Size Tolerance | 95% passing through max grain size |
| Pack Size | 1 Bag = 50 Kg |
Technical Properties
| PCEOrton | 32/33 1717/1743 |
| Grain Size | 0 - 0.5 mm |
| Service Temp | 1550°C |
| Sintering Temp | 1100°C |
Chemical Analysis
| Al2O3 Min | 50% |
| Fe2O3 Max | 2.0% |
Additional Information
| Setting | Air Setting |
| Size Tolerance | 95% passing through max grain size |
| Pack Size | 1 Bag = 50 Kg |
Technical Properties
| PCEOrton | 33 / 1743 |
| Grain Size | 0 - 0.5 mm |
| Service Temp | 1650°C |
| Sintering Temp | 1100°C |
Chemical Analysis
| Al2O3 Min | 60% |
| Fe2O3 Max | 2.0% |
Additional Information
| Setting | Air Setting |
| Size Tolerance | 95% passing through max grain size |
| Pack Size | 1 Bag = 50 Kg |
Technical Properties
| PCEOrton | 34 / 1763 |
| Grain Size | 0 - 0.5 mm |
| Service Temp | 1500°C |
| Sintering Temp | 1100°C |
Chemical Analysis
| Al2O3 Min | 60% |
| Fe2O3 Max | 3.8% |
Additional Information
| Setting | Air Setting |
| Size Tolerance | 95% passing through max grain size |
| Pack Size | 1 Bag = 50 Kg |
Technical Properties
| PCEOrton | 35 / 1785 |
| Grain Size | 0 - 0.5 mm |
| Service Temp | 1500°C |
| Sintering Temp | 1100°C |
Chemical Analysis
| Al2O3 Min | 70% |
| Fe2O3 Max | 3.8% |
Additional Information
| Setting | Air Setting |
| Size Tolerance | 95% passing through max grain size |
| Pack Size | 1 Bag = 50 Kg |
Technical Properties
| PCEOrton | 36 / 1804 |
| Grain Size | 0 - 0.5 mm |
| Service Temp | 1600°C |
| Sintering Temp | 1100°C |
Chemical Analysis
| Al2O3 Min | 80% |
| Fe2O3 Max | 3.5% |
Additional Information
| Setting | Air Setting |
| Size Tolerance | 95% passing through max grain size |
| Pack Size | 1 Bag = 50 Kg |
Technical Properties
| PCEOrton | 31/32 1683/1717 |
| Grain Size | 0 - 0.5 mm |
| Service Temp | 1550°C |
| Sintering Temp | 900°C |
Chemical Analysis
| Al2O3 Min | 40% |
| Fe2O3 Max | 1.5% |
Additional Information
| Setting | Air Setting |
| Pack Size | 1 Bag = 50 Kg |
Technical Properties
| PCEOrton | 20 / 1564 |
| Grain Size | 0 - 1 mm |
| Service Temp | 1350°C |
| Sintering Temp | 1100°C |
Chemical Analysis
| Al2O3 Min | 22% |
| Fe2O3 Max | 2.0% |
Additional Information
| Setting | Air Setting |
| Size Tolerance | 95% passing through max grain size |
| Pack Size | 1 Bag = 50 Kg |
Technical Properties
| PCEOrton | 35 / 1785 |
| Grain Size | 0 - 0.5 mm |
| Service Temp | 1550°C |
| Sintering Temp | 1100°C |
Chemical Analysis
| Al2O3 Min | 70% |
| Fe2O3 Max | 1.5% |
Additional Information
| Setting | Air Setting |
| Size Tolerance | 95% passing through max grain size |
| Pack Size | 1 Bag = 50 Kg |
Technical Properties
| PCEOrton | 36 / 1804 |
| Grain Size | 0 - 0.5 mm |
| Service Temp | 1700°C |
| Sintering Temp | 1100°C |
Chemical Analysis
| Al2O3 Min | 84% |
| Fe2O3 Max | 1.5% |
Additional Information
| Setting | Air Setting |
| Size Tolerance | 95% passing through max grain size |
| Pack Size | 1 Bag = 50 Kg |
Technical Properties
| PCEOrton | 37 / 1820 |
| Grain Size | 0 - 0.5 mm |
| Service Temp | 1700°C |
| Sintering Temp | 1100°C |
Chemical Analysis
| Al2O3 Min | 89% |
| Fe2O3 Max | 1.0% |
Additional Information
| Setting | Air Setting |
| Size Tolerance | 95% passing through max grain size |
| Pack Size | 1 Bag = 50 Kg |
Technical Properties
| PCEOrton | 35 / 1785 |
| Grain Size | 0 - 0.5 mm |
| Service Temp | 1650°C |
| Sintering Temp | 1250°C |
Chemical Analysis
| Al2O3 Min | 64% |
| Fe2O3 Max | 0.6% |
Additional Information
| Setting | Air Setting |
| Size Tolerance | 95% passing through max grain size |
| Pack Size | 1 Bag = 50 Kg |
Technical Properties
| PCEOrton | 36 / 1804 |
| Grain Size | 0 - 0.5 mm |
| Service Temp | 1650°C |
| Sintering Temp | 1450°C |
Chemical Analysis
| Al2O3 Min | 55% |
| Fe2O3 Max | 0.5% |
| ZrO2 Min | 15% |
Additional Information
| Setting | Air Setting |
| Size Tolerance | 95% passing through max grain size |
| Pack Size | 1 Bag = 50 Kg |
Technical Properties
| PCEOrton | 35 / 1785 |
| Grain Size | 0 - 0.3 mm |
| Service Temp | 1650°C |
| Sintering Temp | - |
| Ca OMax | 6% |
Chemical Analysis
| Al2O3 Min | 60% |
| Fe2O3 Max | 0.5% |
| ZrO2 Min | 13.5% |
Additional Information
| Setting | Air Setting |
| Size Tolerance | 95% passing through max grain size |
| Pack Size | 1 Bag = 50 Kg |
Technical Properties
| Service Temp | 1400°C |
| Refractoriness | 20/23 1564/1605°C |
| Grain Size | max 5 mm |
| Bulk Density Min | 2.10 g/cc |
| CCS110 | 250 Kg/cm² |
| CCS1350 | 225 Kg/cm² |
| PLC800 Max | -0.12% |
| PLC1100 Max | -0.12% |
| PLC1350 Max | +/-1.0% |
| Thermal Conductivity400 | 0.74 |
| Thermal Conductivity600 | 0.78 |
| Thermal Conductivity800 | 0.84 |
Chemical Analysis
| Al2O3 Min | 45% |
| Fe2O3 Max | 4% |
Additional Information
| Bond | Hydraulic |
| Method | Vibro Casting |
| Water Req | 11-12% |
Technical Properties
| Service Temp | 1350°C |
| Grain Size | max 5 mm |
| Bulk Density Min | 2.20 g/cc |
| CCS110 | 400 Kg/cm² |
| CCS1350 | 300 Kg/cm² |
| PLC800 Max | -0.12% |
| PLC1100 Max | -0.15% |
| PLC1350 Max | -0.8% |
| Thermal Conductivity400 | 0.71 |
| Thermal Conductivity600 | 0.80 |
| Thermal Conductivity800 | 0.84 |
Chemical Analysis
| Al2O3 Min | 45% |
| Fe2O3 Max | 4% |
Additional Information
| Bond | Hydraulic |
| Method | Vibro Casting |
| Water Req | 11-12% |
Technical Properties
| Service Temp | 1450°C |
| Refractoriness | 31/32 1683/1717°C |
| Grain Size | max 5 mm |
| Bulk Density Min | 2.50 g/cc |
| CCS110 | 350 Kg/cm² |
| CCS1450 | 450 Kg/cm² |
| PLC800 Max | -0.12% |
| PLC1100 Max | -0.18% |
| PLC1450 Max | -0.8% |
| Thermal Conductivity400 | 0.93 |
| Thermal Conductivity600 | 0.95 |
| Thermal Conductivity800 | 0.98 |
Chemical Analysis
| Al2O3 Min | 70% |
| Fe2O3 Max | 4.2% |
Additional Information
| Bond | Hydraulic |
| Method | Vibro Casting |
| Water Req | 11-12% |
Technical Properties
| Service Temp | 1500°C |
| Grain Size | max 5 mm |
| Refractoriness | 30/31 1665/1683°C |
| Bulk Density110 | 2100 Kg/m³ |
| CCS110 | 350 Kg/cm² |
| CCS800 | 270 Kg/cm² |
| CCS1100 | 220 Kg/cm² |
| PLC800 | -0.12% |
| PLC1100 | -0.18% |
| PLC1500 | -0.80% |
| Thermal Conductivity500 | 0.76 |
| Thermal Conductivity800 | 0.80 |
Chemical Analysis
| Al2O3 Min | 50% |
| Fe2O3 Max | 1.5% |
Additional Information
| Bond | Hydraulic |
| Method | Vibro Casting |
| Water Req | 11-12% |
Technical Properties
| Service Temp | 1600°C |
| Grain Size | max 5 mm |
| Refractoriness | 31/32 1683/1717°C |
| Bulk Density110 | 2200 Kg/m³ |
| CCS110 | 350 Kg/cm² |
| CCS800 | 280 Kg/cm² |
| CCS1100 | 220 Kg/cm² |
| PLC800 | -0.12% |
| PLC1100 | -0.18% |
| PLC1500 | -0.70% |
| Thermal Conductivity500 | 0.78 |
| Thermal Conductivity800 | 0.85 |
Chemical Analysis
| Al2O3 Min | 60% |
| Fe2O3 Max | 1.0% |
Additional Information
| Bond | Hydraulic |
| Method | Vibro Casting |
| Water Req | 11-12% |
Technical Properties
| Service Temp | 1700°C |
| Grain Size | max 5 mm |
| Refractoriness | 37 / 1820°C |
| Bulk Density110 | 2800 Kg/m³ |
| CCS110 | 600 Kg/cm² |
| CCS1500 | 650 Kg/cm² |
| PLC800 | -0.06% |
| PLC1100 | -0.12% |
| PLC1500 | -0.80% |
| Thermal Conductivity500 | 1.18 |
| Thermal Conductivity800 | 1.28 |
Chemical Analysis
| Al2O3 Min | 90% |
| Fe2O3 Max | 0.8% |
Additional Information
| Bond | Hydraulic |
| Method | Vibro Casting |
| Water Req | 8-9% |
Royal HARC-50
View product detailsTechnical Properties
| Specific Surface | 3600-4400 cm² |
| Residue170 Mesh | 10% max |
| CCS24h | 300 Kg/cm² (min) |
| CCS72h | 350 Kg/cm² (min) |
Chemical Analysis
| Al2O3 | 50.0% min |
| CaO | 35.0% max |
| Fe2O3 | 4.00% max |
| SiO2 | 6.00% max |
Additional Information
| Setting Time Initial | 30 min (min) |
| Setting Time Final | 400 min (min) |
| Pack Size | 1 Bag = 50 Kg |
Technical Properties
| Service Temp | 1500°C |
| Grain Size | max 6 mm |
| Bulk Density110 Min | 2.20 g/cc |
| CCS110 | 650 Kg/cm² |
| CCS1100 | 750 Kg/cm² |
| CCS1400 | 900 Kg/cm² |
| PLC1400 | +/-1.0% |
Chemical Analysis
| Al2O3 | 43% |
| Fe2O3 | 1.5% |
Additional Information
| Recommended Water | 6.5-7.5% |
| Mixing Time | 5-8 min |
| Shelf Life | 6 months |
Technical Properties
| Service Temp | 1500°C |
| Grain Size | max 6 mm |
| Bulk Density110 Min | 2.35 g/cc |
| CCS110 | 650 Kg/cm² |
| CCS1100 | 800 Kg/cm² |
| CCS1400 | 1000 Kg/cm² |
| PLC1400 | +/-1.0% |
Chemical Analysis
| Al2O3 | 49% |
| Fe2O3 | 1.5% |
Additional Information
| Recommended Water | 6.5-7.5% |
| Mixing Time | 5-8 min |
| Shelf Life | 6 months |
Technical Properties
| Service Temp | 1600°C |
| Grain Size | max 6 mm |
| Bulk Density110 Min | 2.40 g/cc |
| CCS110 | 650 Kg/cm² |
| CCS1100 | 800 Kg/cm² |
| CCS1400 | 1000 Kg/cm² |
| PLC1400 | +/-1.0% |
Chemical Analysis
| Al2O3 | 58-60% |
| Fe2O3 | 1.5% |
Additional Information
| Recommended Water | 6-7% |
| Mixing Time | 5-8 min |
| Shelf Life | 6 months |
Technical Properties
| Service Temp | 1600°C |
| Grain Size | max 6 mm |
| Bulk Density110 Min | 2.75 g/cc |
| CCS110 | 750 Kg/cm² |
| CCS1100 | 850 Kg/cm² |
| CCS1400 | 1000 Kg/cm² |
| PLC1400 | +/-1.0% |
Chemical Analysis
| Al2O3 | 70% |
| Fe2O3 | 1.6% |
Additional Information
| Recommended Water | 5.5-6.5% |
| Mixing Time | 5-8 min |
| Shelf Life | 6 months |
Technical Properties
| Service Temp | 1700°C |
| Grain Size | max 6 mm |
| Bulk Density110 Min | 2.75 g/cc |
| CCS110 | 750 Kg/cm² |
| CCS1100 | 1000 Kg/cm² |
| CCS1450 | 1200 Kg/cm² |
| PLC1450 | +/-0.8% |
Chemical Analysis
| Al2O3 | 80% |
| Fe2O3 | 1.85% |
Additional Information
| Recommended Water | 5-6% |
| Mixing Time | 5-8 min |
| Shelf Life | 6 months |
Technical Properties
| Service Temp | 1700°C |
| Grain Size | max 6 mm |
| Bulk Density110 Min | 3.00 g/cc |
| CCS110 | 800 Kg/cm² |
| CCS1100 | 900 Kg/cm² |
| CCS1450 | 1200 Kg/cm² |
| PLC1450 | +/-0.8% |
Chemical Analysis
| Al2O3 | 88% |
| Fe2O3 | 0.7% |
Additional Information
| Recommended Water | 4.5-5.5% |
| Mixing Time | 5-8 min |
| Shelf Life | 6 months |
Technical Properties
| Service Temp | 1650°C |
| Grain Size | max 1 mm |
Chemical Analysis
| Al2O3 | 83.5% |
| Fe2O3 | 1.4% |
| CaO | 6.0% |
Additional Information
| Bond | Hydraulic |
| Method | Trowelling |
| Recommended Water | 12-16% |
| Shelf Life | 9 months |
| Application Area | Coil coating for induction furnace lining systems |
Technical Properties
| Service Temp | 1100°C |
| PCEOrton | 23 / 1605 |
| App Porosity Min | ≥60% |
| Bulk Density | 0.9 - 1.0 g/cm³ |
| CCSMin | ≥22 Kg/cm² |
| PLC | +/-0.5% at 1100°C/5 hrs |
| Thermal Conductivity600 | 0.25 kcal/m·hr·°C |
Chemical Analysis
| Al2O3 Min | 22% |
| Fe2O3 Max | 2.0% |
Additional Information
| Size Tolerance | ±1 mm on standard bricks |
Technical Properties
| Service Temp | 1300°C |
| PCEOrton | 29 / 1659 |
| App Porosity Min | ≥60% |
| Bulk Density | 0.95 - 1.05 g/cm³ |
| CCSMin | ≥30 Kg/cm² |
| PLC | +/-1.5% at 1350°C/5 hrs |
| Thermal Conductivity600 | 0.30 kcal/m·hr·°C |
Chemical Analysis
| Al2O3 Min | 30% |
| Fe2O3 Max | 2.0% |
Additional Information
| Size Tolerance | ±1 mm on standard bricks |
Technical Properties
| Service Temp | 1400°C |
| PCEOrton | 30/31 1665/1683 |
| App Porosity Min | ≥60% |
| Bulk Density | 1.00 - 1.10 g/cm³ |
| CCSMin | ≥30 Kg/cm² |
| PLC | +/-1.5% at 1400°C/5 hrs |
| Thermal Conductivity600 | 0.32 kcal/m·hr·°C |
Chemical Analysis
| Al2O3 Min | 40% |
| Fe2O3 Max | 1.5% |
Additional Information
| Size Tolerance | ±1 mm on standard bricks |
Technical Properties
| Service Temp | 1300°C |
| PCEOrton | 23 / 1605 |
| App Porosity Min | ≥70% |
| Bulk Density | 0.50 - 0.55 g/cm³ |
| CCSMin | ≥8 Kg/cm² |
| PLC | +/-1% at 1250°C/24 hrs |
| Thermal Conductivity600 | 0.22 kcal/m·hr·°C |
Chemical Analysis
| Al2O3 Min | 40% |
| Fe2O3 Max | 1.0% |
Additional Information
| Size Tolerance | ±1 mm on standard bricks, ±1% or ±1.5 mm on shaped bricks |
Technical Properties
| Service Temp | 1350°C |
| PCEOrton | 31 / 1683 |
| App Porosity Min | ≥60% |
| Bulk Density | 0.75 - 0.80 g/cm³ |
| CCSMin | ≥25 Kg/cm² |
| PLC | +/-1% at 1300°C/24 hrs |
| Thermal Conductivity600 | 0.27 kcal/m·hr·°C |
Chemical Analysis
| Al2O3 Min | 50% |
| Fe2O3 Max | 1.2% |
Additional Information
| Size Tolerance | ±1 mm on standard bricks, ±1% or ±1.5 mm on shaped bricks |
Technical Properties
| Service Temp | 1400°C |
| PCEOrton | 33 / 1743 |
| App Porosity Min | ≥58% |
| Bulk Density | 0.78 - 0.85 g/cm³ |
| CCSMin | ≥30 Kg/cm² |
| PLC | +/-1% at 1400°C/5 hrs |
| Thermal Conductivity600 | 0.32 kcal/m·hr·°C |
Chemical Analysis
| Al2O3 Min | 58% |
| Fe2O3 Max | 1.2% |
Additional Information
| Size Tolerance | ±1 mm on standard bricks, ±1% or ±1.5 mm on shaped bricks |
Technical Properties
| Service Temp | 1500°C |
| PCEOrton | 36 / 1804 |
| App Porosity Min | ≥58% |
| Bulk Density | 1.00 - 1.10 g/cm³ |
| CCSMin | ≥30 Kg/cm² |
| PLC | +/-1% at 1500°C/5 hrs |
| Thermal Conductivity600 | 0.36 kcal/m·hr·°C |
Chemical Analysis
| Al2O3 Min | 60% |
| Fe2O3 Max | 1.0% |
Additional Information
| Size Tolerance | ±1 mm on standard bricks, ±1% or ±1.5 mm on shaped bricks |
Technical Properties
| Service Temp | 1600°C |
| PCEOrton | 37 / 1820 |
| App Porosity Min | ≥55% |
| Bulk Density | 1.10 - 1.20 g/cm³ |
| CCSMin | ≥35 Kg/cm² |
| PLC | +/-1% at 1550°C/5 hrs |
| Thermal Conductivity600 | 0.40 kcal/m·hr·°C |
Chemical Analysis
| Al2O3 Min | 70% |
| Fe2O3 Max | 0.8% |
Additional Information
| Size Tolerance | ±1 mm on standard bricks, ±1% or ±1.5 mm on shaped bricks |
ROYALYTE-7
View product detailsTechnical Properties
| Service Temp | 1100°C |
| Grain Size | max 6 mm |
| Dry Density110 | 850 kg/m³ |
| CCS110 | ≥12 Kg/cm² |
| CCS800 | ≥5 Kg/cm² |
| CCS1100 | ≥6 Kg/cm² |
| PLC800 | +/-0.80% |
| PLC1100 | +/-1.20% |
| Thermal Conductivity500 | 0.19 kcal/m·hr·°C |
| Thermal Conductivity800 | 0.21 kcal/m·hr·°C |
Chemical Analysis
| Al2O3 Min | 30% |
| Fe2O3 Max | 8.2% |
Additional Information
| Bond | Hydraulic |
| Method | Tamping |
| Water Req | 60-65% |
| Pack Size | 1 Bag = 25 Kg |
ROYALYTE-9
View product detailsTechnical Properties
| Service Temp | 1100°C |
| Grain Size | max 6 mm |
| Dry Density110 | 1000 kg/m³ |
| CCS110 | ≥15 Kg/cm² |
| CCS800 | ≥7 Kg/cm² |
| CCS1100 | ≥10 Kg/cm² |
| PLC800 | +/-0.70% |
| PLC1100 | +/-1.10% |
| Thermal Conductivity500 | 0.27 kcal/m·hr·°C |
| Thermal Conductivity800 | 0.29 kcal/m·hr·°C |
Chemical Analysis
| Al2O3 Min | 30% |
| Fe2O3 Max | 6.2% |
Additional Information
| Bond | Hydraulic |
| Method | Tamping |
| Water Req | 35-40% |
| Pack Size | 1 Bag = 25 Kg |
ROYALYTE-11
View product detailsTechnical Properties
| Service Temp | 1300°C |
| Grain Size | max 6 mm |
| Dry Density110 | 1250 kg/m³ |
| CCS110 | ≥35 Kg/cm² |
| CCS800 | ≥25 Kg/cm² |
| CCS1100 | ≥20 Kg/cm² |
| CCS1300 | ≥40 Kg/cm² |
| PLC1100 | +/-0.20% |
| PLC1300 | +/-1.0% |
| Thermal Conductivity500 | 0.30 kcal/m·hr·°C |
| Thermal Conductivity800 | 0.33 kcal/m·hr·°C |
Chemical Analysis
| Al2O3 Min | 34% |
| Fe2O3 Max | 3.7% |
Additional Information
| Bond | Hydraulic |
| Method | Tamping |
| Water Req | 32-36% |
| Pack Size | 1 Bag = 25 Kg |
ROYALYTE-13
View product detailsTechnical Properties
| Service Temp | 1350°C |
| Grain Size | max 6 mm |
| Dry Density110 | 1450 kg/m³ |
| CCS110 | ≥50 Kg/cm² |
| CCS800 | ≥35 Kg/cm² |
| CCS1100 | ≥30 Kg/cm² |
| CCS1300 | ≥50 Kg/cm² |
| PLC800 | +/-0.12% |
| PLC1100 | +/-0.20% |
| PLC1300 | +/-0.84% |
| Thermal Conductivity500 | 0.33 kcal/m·hr·°C |
| Thermal Conductivity800 | 0.37 kcal/m·hr·°C |
Chemical Analysis
| Al2O3 Min | 38% |
| Fe2O3 Max | 3.4% |
Additional Information
| Bond | Hydraulic |
| Method | Tamping |
| Water Req | 28-32% |
| Pack Size | 1 Bag = 25 Kg |
ROYALYTE-15
View product detailsTechnical Properties
| Service Temp | 1350°C |
| Grain Size | max 6 mm |
| Dry Density110 | 1600 kg/m³ |
| CCS110 | ≥90 Kg/cm² |
| CCS800 | ≥65 Kg/cm² |
| CCS1100 | ≥60 Kg/cm² |
| CCS1300 | ≥80 Kg/cm² |
| PLC800 | +/-0.12% |
| PLC1100 | +/-0.20% |
| PLC1300 | +/-1.00% |
| Thermal Conductivity500 | 0.45 kcal/m·hr·°C |
| Thermal Conductivity800 | 0.48 kcal/m·hr·°C |
Chemical Analysis
| Al2O3 Min | 38% |
| Fe2O3 Max | 3.4% |
Additional Information
| Bond | Hydraulic |
| Method | Tamping |
| Water Req | 26-30% |
| Pack Size | 1 Bag = 25 Kg |
ROYALYTE-11Li
View product detailsTechnical Properties
| Service Temp | 1300°C |
| Grain Size | max 6 mm |
| Bulk Density110 | 1250 kg/m³ |
| CCS110 | ≥45 Kg/cm² |
| CCS800 | ≥30 Kg/cm² |
| CCS1100 | ≥30 Kg/cm² |
| CCS1300 | ≥50 Kg/cm² |
| PLC800 | +/-0.12% |
| PLC1100 | +/-0.20% |
| PLC1300 | +/-1.0% |
| Thermal Conductivity500 | 0.33 kcal/m·hr·°C |
| Thermal Conductivity800 | 0.36 kcal/m·hr·°C |
Chemical Analysis
| Al2O3 Min | 43% |
| Fe2O3 Max | 1.5% |
Additional Information
| Bond | Hydraulic |
| Method | Tamping |
| Water Req | 32-36% |
| Pack Size | 1 Bag = 25 Kg |
ROYALYTE-9Li
View product detailsTechnical Properties
| Service Temp | 1300°C |
| Grain Size | max 6 mm |
| Bulk Density110 | 900-1100 kg/m³ |
| CCS110 | 25 Kg/cm² |
| CCS815 | 15 Kg/cm² |
| PLC815 | +/-0.5% |
| PLC1250 | +/-1.5% |
| Thermal Conductivity600 | 0.32 W/mK |
Chemical Analysis
| Al2O3 Min | 45% |
| Fe2O3 Max | 1.5% |
Additional Information
| Bond | Hydraulic |
| Method | Tamping/Gunning |
| Water Req | 50-55% |
| Pack Size | 1 Bag = 25 Kg |
| Shelf Life | 9 months |
ROYALYTE-13Li
View product detailsTechnical Properties
| Service Temp | 1350°C |
| Grain Size | max 6 mm |
| Bulk Density110 | 1450 kg/m³ |
| CCS110 | ≥15 Kg/cm² |
| CCS800 | ≥7 Kg/cm² |
| CCS1100 | ≥10 Kg/cm² |
| PLC800 | -0.12% |
| PLC1100 | +/-1.20% |
| PLC1300 | +/-0.80% |
| Thermal Conductivity500 | 0.38 kcal/m·hr·°C |
| Thermal Conductivity800 | 0.41 kcal/m·hr·°C |
Chemical Analysis
| Al2O3 Min | 44% |
| Fe2O3 Max | 1.5% |
Additional Information
| Bond | Hydraulic |
| Method | Tamping |
| Water Req | 32-36% |
| Pack Size | 1 Bag = 25 Kg |
ROYALYTE-15Li
View product detailsTechnical Properties
| Service Temp | 1400°C |
| Grain Size | max 6 mm |
| Bulk Density110 | 1600 kg/m³ |
| CCS110 | ≥35 Kg/cm² |
| CCS800 | ≥25 Kg/cm² |
| CCS1100 | ≥20 Kg/cm² |
| CCS1300 | ≥40 Kg/cm² |
| PLC800 | +/-0.12% |
| PLC1100 | +/-0.20% |
| Thermal Conductivity500 | 0.43 kcal/m·hr·°C |
| Thermal Conductivity800 | 0.46 kcal/m·hr·°C |
Chemical Analysis
| Al2O3 Min | 45% |
| Fe2O3 Max | 1.5% |
Additional Information
| Bond | Hydraulic |
| Method | Tamping |
| Water Req | 30-34% |
| Pack Size | 1 Bag = 25 Kg |
Technical Properties
| Flexural Strength7d | 35 Kg/cm² |
| Compressive Strength7d | 100 Kg/cm² |
Additional Information
| Working Time | 15 min at 270±2°C |
| Application Area | For laying of acid resisting brick & tiles |
Technical Properties
| Flexural Strength7d | 40 Kg/cm² |
| Compressive Strength7d | 150 Kg/cm² |
Additional Information
| Working Time | 20 min at 270±2°C |
| Application Area | For laying of acid resisting brick & tiles |
Royal Silica Ramming Mass
View product detailsTechnical Properties
| Sintering Temp Min | 1200°C |
| PCEMin | 32 / 1717 |
| Density After Ramming | 2.35-2.5 g/cm³ |
| LOIMax | 0.20% |
Chemical Analysis
| SiO2 Min | 98% |
| Fe2O3 Max | 0.05% |
| Al2O3 Max | 0.3% |
Additional Information
| Application Temp Max | 1700°C |
| Grading | 0-5 mm |
| Application Area | Lining of coreless & foundry |
| Pack Size | 1 Bag = 50 Kg (double HDPE) or as per customer requirement |
| Shelf Life | 6 months when stored in a dry, covered area |
Technical Properties
| Service Temp | 1700°C |
| Grain Size | max 6 mm |
| Bulk Density110 Min | 2.70 g/cc |
| CCS110 | 300 Kg/cm² |
| CCS800 | 400 Kg/cm² |
| CCSHigh Temperature | 600 Kg/cm² |
| PLC800 | +/-0.30% |
| PLCHigh Temperature | +/-0.80% |
| Recommended Liquid Binder | 11-12% |
Chemical Analysis
| Al2O3 | 87-89% |
| Fe2O3 | 0.8-1.0% |
Additional Information
| Shelf Life | 12 months |
| Application Area | Plastic ramming mass for refractory lining and repair |
Technical Properties
| Service Temp | 1600°C |
| Grain Size | max 6 mm |
| Bulk Density110 Min | 2.60 g/cc |
| CCS110 | 300 Kg/cm² |
| CCS800 | 400 Kg/cm² |
| CCSHigh Temperature | 550 Kg/cm² |
| PLC800 | +/-0.30% |
| PLCHigh Temperature | +/-0.90% |
| Recommended Liquid Binder | 11-13% |
Chemical Analysis
| Al2O3 | 78-80% |
| Fe2O3 | 1.5-1.8% |
Additional Information
| Shelf Life | 12 months |
| Application Area | Plastic ramming mass for refractory lining and repair |
Technical Properties
| Service Temp | 1500°C |
| Grain Size | max 6 mm |
| Bulk Density110 Min | 2.50 g/cc |
| CCS110 | 250 Kg/cm² |
| CCS800 | 350 Kg/cm² |
| CCSHigh Temperature | 500 Kg/cm² at 1200°C |
| PLC800 | +/-0.30% |
| PLCHigh Temperature | +/-0.8% at 1200°C |
| Recommended Liquid Binder | 12-13% |
Chemical Analysis
| Al2O3 | 68-70% |
| Fe2O3 | 2.0-2.2% |
Additional Information
| Shelf Life | 12 months |
| Application Area | Plastic ramming mass for refractory lining and repair |
Technical Properties
| Service Temp | 1400°C |
| Grain Size | max 6 mm |
| Bulk Density110 Min | 2.20 g/cc |
| CCS110 | 200 Kg/cm² |
| CCS800 | 300 Kg/cm² |
| CCSHigh Temperature | 450 Kg/cm² at 1200°C |
| PLC800 | +/-0.50% |
| PLCHigh Temperature | +/-0.8% at 1200°C |
| Recommended Liquid Binder | 12-13% |
Chemical Analysis
| Al2O3 | 57-59% |
| Fe2O3 | 2.0-2.2% |
Additional Information
| Shelf Life | 12 months |
| Application Area | Plastic ramming mass for refractory lining and repair |
Technical Properties
| Service Temp | 1400°C |
| Grain Size | max 6 mm |
| Bulk Density110 Min | 2.15 g/cc |
| CCS110 | 200 Kg/cm² |
| CCS800 | 300 Kg/cm² |
| CCSHigh Temperature | 450 Kg/cm² at 1200°C |
| PLC800 | +/-0.50% |
| PLCHigh Temperature | +/-0.8% at 1200°C |
| Recommended Liquid Binder | 13-14% |
Chemical Analysis
| Al2O3 | 43-45% |
| Fe2O3 | 1.6-1.8% |
Additional Information
| Shelf Life | 6 months |
| Application Area | Plastic ramming mass for refractory lining and repair |
ROYAL PLAST F-45 AB
View product detailsTechnical Properties
| Apparent Porosity After1000 C | 21% |
| Bulk Density After110 C | 2.32 g/cm³ |
| Bulk Density After1000 C | 2.15 g/cm³ |
| CCSAfter110 C | 85 Kg/cm² |
| CCSAfter800 C | 223 Kg/cm² |
| CCSAfter1000 C | 230 Kg/cm² |
| CCSAfter1200 C | 180 Kg/cm² |
| CCSAfter1400 C | 210 Kg/cm² |
| CMRAfter110 C | 27 Kg/cm² |
| CMRAfter800 C | 25 Kg/cm² |
| CMRAfter1000 C | 35 Kg/cm² |
| CMRAfter1200 C | 40 Kg/cm² |
| CMRAfter1400 C | 45 Kg/cm² |
| PLCAfter110 C | -1.38% |
| PLCAfter800 C | -1.40% |
| PLCAfter1000 C | -1.50% |
| PLCAfter1200 C | -1.45% |
| PLCAfter1400 C | -1.25% |
| Thermal Conductivity500 | 0.98 W/mK |
| Thermal Conductivity800 | 1.04 W/mK |
| Thermal Conductivity1000 | 1.17 W/mK |
| Max Service Temp | 1500°Cspec: 1500°C |
Chemical Analysis
| Al2O3 | 42.40%spec: 40-45 Wt% |
| SiO2 | 50.60%spec: 50-55 Wt% |
| Fe2O3 | 1.12%spec: 1.0-1.5 Wt% |
| TiO2 | 2.00%spec: 1.5-2.5 Wt% |
Additional Information
| Pack Size | 1 Bag = 50 Kg |
SUPER ALX-AB
View product detailsTechnical Properties
| Apparent Porosity After1000 C | 19% |
| Bulk Density After110 C | 2.59 g/cm³ |
| Bulk Density After1000 C | 2.44 g/cm³ |
| CCSAfter110 C | 110 Kg/cm² |
| CCSAfter800 C | 250 Kg/cm² |
| CCSAfter1000 C | 295 Kg/cm² |
| CCSAfter1200 C | 230 Kg/cm² |
| CCSAfter1400 C | 240 Kg/cm² |
| CMRAfter110 C | 30 Kg/cm² |
| CMRAfter800 C | 40 Kg/cm² |
| CMRAfter1000 C | 45 Kg/cm² |
| CMRAfter1200 C | 40 Kg/cm² |
| CMRAfter1400 C | 55 Kg/cm² |
| PLCAfter110 C | -1.15% |
| PLCAfter800 C | -0.27% |
| PLCAfter1000 C | -0.30% |
| PLCAfter1200 C | -0.44% |
| PLCAfter1400 C | -0.56% |
| Thermal Conductivity500 | 1.42 W/mK |
| Thermal Conductivity800 | 1.52 W/mK |
| Thermal Conductivity1000 | 1.58 W/mK |
| Max Service Temp | 1600°Cspec: 1600°C |
Chemical Analysis
| Al2O3 | 72.80%spec: 72-76 Wt% |
| SiO2 | 20.60%spec: 20-25 Wt% |
| Fe2O3 | 1.10%spec: 1.0-1.5 Wt% |
| TiO2 | 1.80%spec: 1.5-2.8 Wt% |
Additional Information
| Pack Size | 1 Bag = 50 Kg |
Not sure which grade fits your furnace? Our refractory best practices and application notes cover lining selection, castable dry-out, thermal shock, and mortar joints.
